Preowned Atlas LCR40 Passive Component Analyser Made By Peak Electronic Design Ltd

This is a  Preowned Atlas LCR40 Passive Component Analyser Made By Peak Electronic Design Ltd. Purported to identify and analyse a wide range of Inductors, Capacitors and Resistors using automatically selected test frequencies.

In pretty good cosmetic and working condition, it dates to 2005, and comes with 2mm plugs and sockets but no instructions; these are available to download from the internet. When switching on the LCR is recommending a calibration in 2006, however, according to Peak Electronic recalibration is not a necessity.

Summary Specification.

• Resistance: 1 Ohm to 2 MegOhms, resolution typically 0.6 Ohms, accuracy typically ±1.0% ±1.2 Ohms
• Inductance: 1uH to 2H, resolution typically 0.8uH, accuracy typically ±1.5% ±1.6uH
• Capacitance: 0.5pF to 10000uF, resolution typical 0.5pF, accuracy typically ±1.5% ±1.0pF
• Open circuit test voltage: ±1.05V
• Short circuit test current: ±3.25mA
• Test frequencies: DC, 1kHz, 14.925kHz and 200kHz, ±1.5%
• Sine purity: -60dB 3rd harmonic typical
• Operating temperature range: 15°C to 35°C (60°F to 95°F)
• Battery type: GP23A or V23A or MN21 (12V 55mAH type)

• Battery life: Typically ~1600 operations at <1 minute per operation
• Display type: Alphanumeric LCD (low level backlight)

Please click on the following link for more second hand test equipment.
